BCO-3000-RPL: fanless box PC equipped with 13th generation Raptor Lake

June 2024

BCO-3000-RPL: fanless box PC equipped with 13th generation Raptor Lake

C&T Solutions presents BCO-3000-RPL, the new family of fanless embedded computers featuring 13th generation Intel Core processors with Raptor Lake architecture. BCO-3000-RPL embedded PC allows the installation of up to 64GB of DDR4 RAM and offers a wide selection of integrated I/O ports, both on the front and back, including one HDMI, two DisplayPort, four COM, three RJ45 2.5 GbE, six USB 3.2 Gen2, two USB 3.2 Gen1, two USB 2.0, and eight isolated DI/O. For data storage, an M.2 M-key SSD can be integrated into the dedicated slot, while expansion options include M.2 B-key and M.2 E-key slots that can be used for 5G, 4G, LTE, AI, and Wi-Fi wireless communications. Thanks to the high-strength aluminum unibody enclosure and specifically selected hardware, the BCO-3000-RPL series offers extended operation from 0°C to +50°C and power input of 9-36Vdc.

Datasheet

BCO-3000-RPL: fanless box PC equipped with 13th generation Raptor Lake2024-06-19T10:12:07+02:00

AIE-CO21/31: Embedded PC with NVIDIA Jetson Orin Nano



June 2024

AIE-CO21/31: Embedded PC with NVIDIA Jetson Orin Nano

Aetina Corporation introduces AIE-CO21/31, the new Edge Computing platform for industrial artificial intelligence applications based on the NVIDIA Jetson Orin Nano and suitable for all AI applications where maintenance, performance and reliability are of crucial importance. AIE-CO21/31 integrates 4GB or 8GB Jetson Orin Nano and offers up to 40 TOPS, 1024 NVIDIA Ampere cores and 32 Tensor cores. AIE-CO21/31 sets a new standard for entry-level artificial intelligence in the smallest Jetson form factor. AIE-CO21/31 offers extensive I/O including a GbE port, two USB 3.2 Gen2, one USB OTG Type C, one HDMI, GPIO, UART, I2C and CANBus. In addition, AIE-CO21/31 can be equipped with WIFI/BT via M.2 expansion slots. For data storage, the built-in 128GB can be expanded via M.2 NVMe module. AIE-CO21/31 has dimensions of 130 x 90.2 x 72 mm and supports wall and DIN-RAIL mounting, an operating temperature of -25°C /+55°C and 12-24VDC power supply via 2-pin Terminal Block.

Datasheet

AIE-CO21/31: Embedded PC with NVIDIA Jetson Orin Nano2024-06-19T10:12:18+02:00

DM2-W238: 23.8″ Industrial Display

June 2024

DM2-W238: 23.8″ Industrial Display

IEI Integration Corp. introduces DM2-W238, the new 23.8″ display for panel or VESA mounting, with an elegant and flexible design, ideal for industrial applications. DM2-W238 features a 23.8″ panel in 16:9 format, anti-glare and anti-UV with IP65 protection, and an ultra-thin aluminum front bezel, a ten-point capacitive multitouch touchscreen, and an operating temperature range of 0°C to +50°C. The I/O ports are located at the back and include VGA, Display Port, HDMI, four USB 3.2 Gen2 Type-A, and one USB 3.2 Gen1 Type-B. The display control buttons are located at the bottom, not visible from the front, allowing easy control of the device. Additionally, DM2-W238 is equipped with front-facing speakers and an integrated camera, ideal for facial recognition applications. DM2-W238 display has an extended power input range of 9-36VDC via terminal block or DC jack.

Datasheet

DM2-W238: 23.8″ Industrial Display2024-06-19T10:12:26+02:00

AGX-ORIN64-HPC: 3U VPX SBC for Artificial Intelligence At-the-Edge (AIAE) Processing

June 2024

AGX-ORIN64-HPC: 3U VPX SBC for Artificial Intelligence At-the-Edge (AIAE) Processing

EIZO Rugged Solutions Inc. has launched the Condor AGX-ORIN64-HPC, a rugged 3U VPX single-board computer aligned with the Sensor Open System Architecture (SOSA) standards. This high-performance module, built on the NVIDIA Jetson AGX Orin SoM, is tailored for AI-intensive C5ISR applications requiring edge processing. It features an NVIDIA Ampere architecture GPU, a 12-core Arm Cortex-A78AE CPU, and 64GB of LPDDR5 memory, providing substantial data processing power and AI acceleration. Connectivity is enhanced with the NVIDIA ConnectX-7 NIC, supporting up to 100Gb/s data transfer. Designed to meet MIL-STD-810 standards, it includes options for expandable storage and versatile I/O capabilities, making it ideal for high-speed data transfers and handling large data volumes in environments sensitive to latency.

Datasheet

AGX-ORIN64-HPC: 3U VPX SBC for Artificial Intelligence At-the-Edge (AIAE) Processing2024-06-19T11:54:50+02:00

R8-EX: Rugged tablet with 12th generation Intel Core CPU and ATEX certification



June 2024

R8-EX: Rugged tablet with 12th generation Intel Core CPU and ATEX certification

Durabook introduces R8-EX, the new ATEX-certified rugged tablet with an 8″ display and 12th generation Intel Core processor, capable of operating in high explosion-hazard areas. R8-EX tablet features an 8″ Full HD LCD display with a resolution of 1280 x 800, a capacitive multi-touch touchscreen, and an optional sunlight-readable configuration. The aluminum casing ensures lightness and resistance to drops from up to 1.2 meters and provides IP66 protection against dust and liquids. The R8-EX tablet complies with MIL-STD-810H, ATEX Zone 2 (Ex II 3G Ex ic IIC T4 Gc and Ex II 3D Ex ic IIIB T135°C Dc) standards and offers extended operation from -20°C to +60°C. The new rugged tablet integrates a solid-state drive with a maximum capacity of 1TB and features numerous I/O ports, including a Thunderbolt 4, a USB 3.2 Gen2 Type-C, audio in/out, a microSD card slot, a docking connector, and a nano SIM card socket.
Additionally, it ensures Dual Band Wireless and Bluetooth connectivity, while GPS and 4G LTE are optionally available, making R8-EX the ideal rugged tablet for industrial applications. The tablet’s battery can be expanded to up to 7200 mAh, ensuring optimal performance even in harsh environments where ATEX certification is required.

Datasheet

R8-EX: Rugged tablet with 12th generation Intel Core CPU and ATEX certification2024-06-19T10:13:03+02:00
