DM-F17A | AP-17 DP-17 |
NAP-17 | VIO-217/MX100 | |
LCD Size | 17″ | 17″ | 17” | 17” |
Max Resolution (W x H) |
1280 x 1024 SXGA |
1280 x 1024 SXGA |
1280 x 1024 SXGA |
1280 x 1024 SXGA |
Aspect Ratio | 5:4 | 4:3 | 4:3 | 4:3 |
Brightness (cd/m2) | 350 | 250 | 250 | 350 |
Contrast Ratio | 1000:1 | 1000:1 | 1000 : 1 | 800:1 |
Input Interface | 1x VGA | 1x VGA | 1x VGA | 1x VGA |
– | 1x DVI-D | 1x DVI-D | 1x DVI-D | |
1x HDMI | – | – | – | |
1x DP | – | – | 1x DP | |
– | – | – | 1x USB 2.0 | |
– | – | – | 1x COM | |
– | – | – | 1x Audio | |
– | Optional: HDMI or DVI-D, S-Video, Quad display for CCTV, TV-Analog |
Optional: HDMI or DVI-D, S-Video, Quad display for CCTV, TV-Analog |
– | |
Touch Screen | Resistive type 5-wire flat touch window/ Penmount 6000 Projected capacitive flat touch window/ EETI EXC7200 |
Optional: Projected Capacitive ( 4-point touch ) Resistive / Capacitive ( single point touch ) |
Optional: Projected Capacitive ( 4-point touch ) Resistive / Capacitive ( single point touch ) |
Resistive 5-wire or 10-point Projected Capacitive |
Front Frame | Aluminum | AP-17: 6mm Aluminum Bezel DP-17: Aluminum Cover |
Aluminum | Aluminum Die-cast |
Input Voltage | 9~36VDC | Auto-sensing 100 to 240VAC, 50 / 60Hz Optional: 48V, 24V or 12VDC power |
Auto-sensing 100 to 240VAC, 50 / 60Hz Optional: 48V, 24V or 12VDC power |
9~48VDC |
Mounting | Panel mount / Rack mount / VESA 100mm x 100mmm | Panel mount / VESA | Panel mount / VESA | Panel mount / Wall / VESA (Opt.) |
Color | Black | Black front Dark grey rear |
Black front Dark grey rear |
Black |
Dimensions (W x D x H mm) |
408.4 x 49.3 x 341.4 | AP-17: 439 x 64.2 x 356.6 DP-17: 408 x 59.5 x 325.6 |
439 x 64.2 x 356.6 | 407.5 x 70.5 x 339 |
Operating Temperature |
-20° to +60°C | 0°C to +55°C | 0°C to +55°C | -10°C to +60°C |
Front Panel Protection |
IP 65 | Protective 3mm glass | IP 65 | IP65 |
Special Approvals | CE, FCC | CE, FCC | CE, FCC | CE, FCC Class A |
Weight (Kg) | 4.4 | AP-17: 6.6 DP-17: 5.8 |
6.6 | 6.38 |
Power Adapter | External | External | External | External |
Ordering Information | DM-F17A/R-R20 DM-F17A/PC-R20 |
AP-17 AP-17/AD2.2H AP-17TRB DP-17 |
NAP-17/AD2.2H NAP-17TRB |
VIO-217R/MX100 VIO-217C/MX100 |
